Mechanical Shock Test Machine Meets ASTM D5487 Packaging Vertical Shock Test

Brand Name : LABTONE

Model Number : HSKT10D

Certification : CE, ISO

Place of Origin : CHINA

MOQ : 1SET

Price : Negotiable

Payment Terms : T/T

Delivery Time : 45 working days

Packaging Details : International wooden case

Supply Ability : 15 Sets / Month

Model : HSKT10D

Table size : 210 x 210

Specimen max weight(kg) : 10

Shock pulse : half sine

Acceleration range (m/s2) : 20----10000

Pulse duration range (ms) : 0.2~11

Contact Now

Mechanical Shock Test Machine Meets ASTM D5487 Packaging Vertical Shock Test

Product description

The precise-type high-acceleration shock tester can provide all half-sine short wave specification specified in JESD22-B110. To meet them, merely change different shock rubber-pad on shock seat. The wave is complete with high repeatability, able to provide user accurate test result.
Conform to different test specs such as JESD22-B110 and IEC spec.

High repeatability on consecutive shock; acceleration +/- 10%; run time +/- 15%; speed deviation +/- 10%.
Table’s four corner-points uniformity P160mm +/- 10%.
Can add spring system to reach the requirement of extra high acceleration specification.

Shock testing systems Specifications

Model HSKT10 HSKT10D
Table size (mm) 200 x200 210 x 210
Specimen max weight(kg) 10 10
Shock pulse Half-sine
Acceleration range (m/s2) 20----1500 20----10000
Pulse duration range (ms) 0.5~11 0.2~11
Seismic base Pneumatic springs device
Utility reqyurements AC220V 50Hz 5A Air pressure:more than 0.5Mpa

Model SKT30 SKT50 SKT100 SKT200 SKT300 SKT600 SKT1000
Table size (cm) 40*40 50*60 70*80 100*100 120*120 150*150 200*200
Maximum Specimen Weight(Kg) 30 50 100 200 300 600 1000
Max acceleration(G) half sine 600 600 600 500 500 300 300
saw-tooth waveform 100 100 100 100 100 100 100
square 150 150 150 150 100 100 100
Pulse Duration (ms) half sine 40—0.2 40~1 40~1 30~2 20~3 20~3 20~3
saw-tooth waveform 18~6 18~6 18~6 18~6 18~6 18~6 18~6
square 30~6 30~6 30~6 30~6 30~6 30~6
Machine Dimension(cm) 120*110*245 130*140*260 130*120*260 150*130*260 200*160*300 230*180*310 250*220*310
Controller cabinet Dimension(cm) W55*D50*H80
Machine Weight(Kg) 1900 2300 3200 4200 8500 15500 19500
Utility 3-phase AC380V 50/60Hz 0.5~0.8MPa
Requirements
Conforming standards GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL

Mechanical Shock Test Machine Meets ASTM D5487 Packaging Vertical Shock Test

Customer Services

Presales:

  • Technical consultation: test method, laboratory planning and suggestion.
  • Equipment selection: selection scheme, FAQ.
  • Product testing scheme.

In-Sales:

  • Customer communication and progress report.
  • Guidance for pre-installation preparation, equipment commissioning and test run.
  • Calibration (when Third Party’s verification is required).

After-Sales:

  • Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.
  • Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.
  • Technical support: special paid services are provided according to customer’s needs.
